Siemens 3KA7131-4AA00 SWITCH DISCONNECTOR 4X315A W/O OP.MECH.


Price:
₦393,624

Description

SWITCH DISCONNECTOR 4X315A W/O OP.MECH.

Model
product brand name SENTRON
product designation Switch disconnector
design of the product Basic versions without handle
design of the load switch / strip form No
type of the driving mechanism / motor drive No
General technical data
number of poles 4
type of device fixed mounting
electrical endurance (switching cycles) / typical 1,500
circuit-breaker / Design 3KA713
mechanical service life (switching cycles) / typical 8,000
type of voltage AC/DC
operating current / at AC / rated value 315 A
operating voltage
● rated value 690 V
● at AC / at 50/60 Hz / rated value 690 V
● at DC / rated value 440 V
Protection class
protection class IP IP00
Current
operating current / at AC-21 / rated value 315 A
current / rated value 315 A
continuous current / rated value 315 A
Suitability
suitability for use
● EMERGENCY OFF switch
● safety switch
Yes Yes
Connections
type of electrical connection
● for main current circuit
Busbar connection
flat connector
Mechanical Design
height 196 mm
width 235 mm
depth 93 mm
mounting type floor mounting
net weight 3.8 kg
Environmental conditions
ambient temperature / during operation
● minimum
● maximum
-20 °C
45 °C
ambient temperature / during storage / minimum -25 °C
